CBC 120 Curved Belt Conveyor


Curve Belt Conveyors (CBC) are built to transport heavy-duty loads and convey at speeds of up to 550 feet per minute. They are designed for stringent environments with continuous or clocked transportation of packages, containers, and packaged goods with changes in direction.

The CBC120 is available in a variety of modular designs ranging from 30º to 90º angles, and in a wide range of standard measurements or customer-specific measurements for integration into new or existing systems.

These conveyors are also equipped with a unique belt guiding system that makes performing maintenance or service work simple. The belt can be replaced in as little as 15 minutes. Whereas replacing a belt on a traditional friction-driven curve can take hours.

Are you interested in this product?
We are here to help.

Contact Us

Featured Video

Features

curved belt conveyor belt change

Quick Belt Changes

In scenarios where belt changes are required, the modular design of our conveyors enables a speedy resolution and minimal downtime, with changes occurring in as little as 15 minutes, instead of the hours required for other solutions.


curved belt conveyor roller system

Highly Durable Guiding Profile

To meet the demands of heavy-duty applications, our curved conveyor solutions are built with offset joints and double seam-secured belt beading, providing guiding profiles that are five times stronger than traditional belt beading. By directly addressing and reducing these common breakage risks, we are able to nearly eliminate maintenance time.


Standard Specs

Max Load Capacity

Up to 485 lbs

Unit Load Capacity

Up to 132 lbs

Nominal Width

Up to 59 in

Inner Radius

Up to 78.74 in

Angles

30º / 45º / 60º / 90º / 180º

Belt Type

2 Ply Polyester

Motor Locations

Inner Radius / Outer Radius / Underslung

Belt Speed

Up to 9.19 ft/s (550+ fpm)

Guard Rails

3.9 – 23.6 in

Power

230 / 480 VAC – 60 Hz

Construction

Aluminum Frame

Accessories

  • VFD Frequency Control on Unit
  • Brake on Drive Unit
  • Photo Eye Flow Control

Warranty

MECHANICAL :: 24 Months

ELECTRICAL :: 12 Months

Services Available

  • Technical Support
  • Installation & Service
  • Prevenative & Routine Maintenance
  • Application Support
  • Operator & Maintenance Training
