BestConnect Balltables

An innovative new design to allow you to easily sort packages and parcels during your manual sortation process. The unit can also be supplied with an integrated weight scale unit with a digital display.

Are you interested in this product?
We are here to help.

Contact Us


Adjustable Height

Telescopic leg sections to raise or lower the conveyor bed height.

Square Tubing Legs

Heavy-duty square tubing legs offer longer service life and stability.

Castors with Brakes

127mm x 38mm Swivel Castors allow easy movement. Castor brakes lock both wheels and swivel simultaneously while the conveyor is in use.

Performance Options

Mettler Toledo Weight Scale

300Kg / 50Kg Calibrated Capacity. Various Display Options and languages available.

Heavy-Duty Castors

150mm x 50mm Swivel Castors for easier rolling over uneven surfaces.

Roller Stop/Connector

Provides a simple mechanical connection between the ball table and conveyor sections. This also acts as a drop-down stop on the ball table.

Standard Specs

Load Capacity

150Kg capacity per linear metre (level.)

Size Options

Length / Width: 650mm x 650mm

Length / Width: 800mm x 800mm

Length / Width: 1000mm x 1000mm

Ball Pitches




(Others Available Upon Request)


MECHANICAL :: 24 Months

Services Available

  • Technical Support
  • Installation & Service
  • Preventive & Routine Maintenance
  • Application Support
  • Operator & Maintenance Training

Document / Resources
